Solar Inverter 5Kva 4000W 48V 220V Pure Sine Wave PWM Off-Grid Hybrid Inverter
Til salgs15 700 kr
Beskrivelse
Solar Inverter 5Kva 4000W 48V 220V Pure Sine Wave PWM Off-Grid Hybrid Inverter,
på lager.
This SPL 5KVA model does not include "parallel kits" & Without parallel function.
ISolar SPL 5KVA is a Competitive Cost 5KVA Continuous /10KVA Surge, 48Vdc input Pure Sine Wave Inverter Charger.
It is PWM Solar Inverter 5KVA 4000W Off Grid Inverter 48V to 220V 50A PWM Inverters Pure Sine Wave Inverter Hybrid Solar Inverter With 60A AC Charger Battery Charger For Home Use.
Design with ac input /output 220-240vac single phase only. ( not Split phase 110/220vac)
This is multi-function inverter/charger ,combining functions of inverter, PWM solar charger and battery charger to offer uninterruptible power support with portable size .
Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current .AC/Solar charger priority ,and acceptable input voltage based on different applications
Features:
Pure sine wave inverter
Built-in PWM solar charge controller
Configurable input voltage range for home applicances and personal computers via LCD setting
Configurable AC/Solar Charger priority via LCD setting
Configurable AC/Solar input priority via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/over temperature/ short circuit protection
Smart charging system optimizes battery performance
Cold start function
Basic System Architechture:
The following illustration sgiws basic application for this inverter/charger .It also includes following devices to have a complete running system :
Generator or Utility
PV modules (Option)
Consult with your system intergrator for other possible system architectures depending on your requirements .This inverter can power all kinds of applicances in home or office environment ,including motor-type applicances such as tube light ,fan,refrigerator and air conditioner
Consult with your system intergrator for other possible system architectures depending on your requirements .This inverter can power all kinds of applicances in home or office environment ,including motor-type applicances such as tube light ,fan,refrigerator and air conditioner
MODEL
ISolar SPL 5K
Rated Power
5000VA/4000W
INPUT
Voltage
230VAC
Selectable Voltage Range
170-280 VAC(For Personal Computers) ; 90-280 VAC(For Home Appliances)
Frequency Range
50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)
230VAC 5%
Surge Power
10000VA
Efficiency(Peak)
93%
Transfer Time
10 ms (For Personal Computers) ; 20 ms (For home Appliances)
Waveform
Pure sine wave
BATTERY & AC CHARGER
Battery Voltage
48 VDC
Floating Charge Voltage
54 VDC
Overcharge Protection
60 VDC
Maximum Charge Current
60A
SOLAR CHARGER(OPTION)
Charging Current
50A
Maximum PV Array Power
2400W
Maximum PV Array Open Voltage
105 VDC
Standby Power Consumption
2 W
PHYSICAL
Dimension,D×W×H (mm)
128×272×355
Net Weight(kgs)
9.8
Package Including :
The unit x 1
User Manual(English) x 1
Communication cable x 1
Software CD x 1
Stikkord: Laderegulator, inverter, lader, solar lader
på lager.
This SPL 5KVA model does not include "parallel kits" & Without parallel function.
ISolar SPL 5KVA is a Competitive Cost 5KVA Continuous /10KVA Surge, 48Vdc input Pure Sine Wave Inverter Charger.
It is PWM Solar Inverter 5KVA 4000W Off Grid Inverter 48V to 220V 50A PWM Inverters Pure Sine Wave Inverter Hybrid Solar Inverter With 60A AC Charger Battery Charger For Home Use.
Design with ac input /output 220-240vac single phase only. ( not Split phase 110/220vac)
This is multi-function inverter/charger ,combining functions of inverter, PWM solar charger and battery charger to offer uninterruptible power support with portable size .
Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current .AC/Solar charger priority ,and acceptable input voltage based on different applications
Features:
Pure sine wave inverter
Built-in PWM solar charge controller
Configurable input voltage range for home applicances and personal computers via LCD setting
Configurable AC/Solar Charger priority via LCD setting
Configurable AC/Solar input priority via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/over temperature/ short circuit protection
Smart charging system optimizes battery performance
Cold start function
Basic System Architechture:
The following illustration sgiws basic application for this inverter/charger .It also includes following devices to have a complete running system :
Generator or Utility
PV modules (Option)
Consult with your system intergrator for other possible system architectures depending on your requirements .This inverter can power all kinds of applicances in home or office environment ,including motor-type applicances such as tube light ,fan,refrigerator and air conditioner
Consult with your system intergrator for other possible system architectures depending on your requirements .This inverter can power all kinds of applicances in home or office environment ,including motor-type applicances such as tube light ,fan,refrigerator and air conditioner
MODEL
ISolar SPL 5K
Rated Power
5000VA/4000W
INPUT
Voltage
230VAC
Selectable Voltage Range
170-280 VAC(For Personal Computers) ; 90-280 VAC(For Home Appliances)
Frequency Range
50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)
230VAC 5%
Surge Power
10000VA
Efficiency(Peak)
93%
Transfer Time
10 ms (For Personal Computers) ; 20 ms (For home Appliances)
Waveform
Pure sine wave
BATTERY & AC CHARGER
Battery Voltage
48 VDC
Floating Charge Voltage
54 VDC
Overcharge Protection
60 VDC
Maximum Charge Current
60A
SOLAR CHARGER(OPTION)
Charging Current
50A
Maximum PV Array Power
2400W
Maximum PV Array Open Voltage
105 VDC
Standby Power Consumption
2 W
PHYSICAL
Dimension,D×W×H (mm)
128×272×355
Net Weight(kgs)
9.8
Package Including :
The unit x 1
User Manual(English) x 1
Communication cable x 1
Software CD x 1
Stikkord: Laderegulator, inverter, lader, solar lader
NB: Knappen for å vise hele beskrivelsen har kun en visuell effekt.
Nøkkelinfo
- Tilstand
- Ny
Beliggenhet
| FINN-kode | 237364572 |
|---|---|
| Sist endret | 2.11.2021 kl. 04:50 |
