Trinnov ST2-PRO Stereo Processor m/Trinnov 3D Measurement microphone

Vi har på lager en ny Trinnov ST-2 Pro Stereo Processor og en ny Trinnov 3D Measurement Microphone vi selger gunstig som en samlet pakke.

kr.49.990,-inkl.mva.(kr.39.992,-eks.mva.).
Veil pris for pakken er kr.75.990,-inkl.mva.

4 kanals enhet!

Trinnov ST2-Pro Stereo Processor med 4 Optimizer lisenser(2 x Stereo lisenser).

4 Analoge innganger,4 Analoge utganger,og 2 x Stereo AES/EBU innganger og utganger.
Prisen vår inkluderer 3D målemikrofon!(Veil pris 3D Målemikrofon kr.10.995,-inkl.mva)

Ta kontakt for mer info!


IMPROVE YOUR STUDIO ACOUSTICS INSTANTLY
Trinnov’s ST2 Pro stereo processor is the ideal monitoring solution for cinema, post-production, broadcast and mastering studios. Sound engineers demand highly accurate monitoring to work with subtlety on effects, EQs, and dynamics.

It’unique loudspeaker and room correction technology will take your audio monitoring chain to the next level, resulting in mixes that translate better through various listening environment and broadcast norms, therefore, increasing repeatability and consistency for better time efficiency.

EXPERIENCE TIME ALIGNMENT
The Optimizer automatically time aligns your speakers with more precision than a human could achieve with a tape measure. Time alignment alone makes a huge difference in terms of stereophonic image, but by working in the time domain and improving both the amplitude and phase response of the loudspeakers, the Optimizer achieves high-resolution stereophonic image and well-focused phantom sources simply not achievable otherwise.



MEET YOUR LOUDSPEAKERS CHARACTERISTICS


The Optimizer provides you with a unique set of data and comprehensive toolbox to get the absolute best from your speakers in any given room. With a single measurement, the Optimizer gives you both the direct response and the global acoustic response of your speakers in the room.

You can then define the target curve that will best meet your loudspeakers characteristics whilst optimizing its global acoustic response. The Optimizer automatically defines the filters that will achieve the required frequency response specified by your target curve. This is particularly useful in post-production studios to comply with SMPTE standards (X-Curve).



SOUND TAILORED TO YOUR ROOM
Trinnov’s sophisticated multi point algorithm can take into account the measurements of different positions to perform the optimization.
A higher weighting may be assigned to the most critical listening position(s), and lower weighting to the remaining points.

Therefore you can create instantly recallable listening positions letting you listen at the sweetest spot wherever you or the producer may sit in the room, making sure the production team hears the same content as you do.



UNIQUE PHASE CORRECTION
The Trinnov ST2 provides highly accurate monitoring by improving the phase response of every speaker offering a wider stereo image and more focused phantom sources.

The Optimizer is the only system on the market that not only compensates for the phase response of a loudspeaker but actually shows you what it does with acoustic graphs where you can see the before and after phase response for any given measurement position.

THE TRINNOV APP


Simply called Trinnov App this new free application for all our users will become a staple in your dock and facilitates set-up and use of all Trinnov processors.

This new macOS App lets you discover all Trinnov machines currently on your network. From it, you can execute basic essential functions from saving and loading presets to control volume or dim and mute. As well no more need of VNC you can now directly launch the web application of your machine(s) to perform a new set-up or calibration.



PRODUCT DESCRIPTION
The Trinnov 3D Measurement Microphone is one of the most critical components of any loudspeaker/room calibration system. Trinnov’s sophisticated algorithms rely not only on extremely accurate acoustic measurements but also on the ability to localize the speakers’ positions and to detect early reflections.

The 3D microphone uses four mic elements in a precise tetrahedral arrangement. Each capsule is individually calibrated at the factory ( 0.1 dB from 20 Hz to 24 kHz). The resulting microphone calibration file is included in the microphone’s box on a USB stick. This file is installed in the Trinnov product being employed and all subsequent measurements are filtered through the calibration coefficients to ensure accuracy.

As each speaker is measured, the resulting sound waves pass through this array of microphones, hitting each one at a slightly different time. Based on this timing, it triangulates the location of the speaker from which the sound arrived. By testing each speaker in turn, Trinnov build a three-dimensional map of where the speakers are relative to the mic (which is placed at the main listening position).

This can be done within 2 of azimuth, 2 of elevation, and less than 1 cm of distance. Trinnov use this information to enable proprietary Remapping technology, in which they translate from the theoretical rendering of the soundtrack to the specifics of your particular room. Remapping uses the two or three speakers closest to the intended location of a sound to create a phantom image of the sound coming from the correct direction.

Among other things, Remapping serves as a bit of a “Universal Translator” between the various audio formats. This is especially important in home cinemas since all three Immersive Audio formats disagree about the specific details of where you should place your speakers. We can solve that problem for you.

FEATURES:
Designed and manufactured in France by Trinnov
4 capsules in tetrahedron configuration
Tridimensional speakers localization and loudspeaker remapping
Individual compensation file
Frequency Response: 0.1 dB across the 20 Hz - 24 kHz frequency range
Spatial Accuracy: 2" in every direction
