Chameleon Labs 7603 MICROPHONE PREAMP & EQ

Chameleon Labs 7603 MICROPHONE PREAMP & EQ.


Veil pris kr.20.585,-inkl.mva.(kr.16.468,-eks.mva.).

Kampanjepris kr.13.990,-inkl.mva.(kr.11.192,-eks.mva).
Gjelder kun lagerførte enheter.
Forbehold om utsolgt!

7603

Line / Mic / DI Pre-Amplifier


7603 FEATURES

Chameleon wound microphone and Line Input transformers and Chameleon output transformer, all with mu-metal housings

High resolution, low noise discrete audio circuitry

Hi-Z Direct Instrument Input (TRS)

Discrete Class A Electronic Topology

Three band, inductor based EQ

48V phantom power for mic input

Selectable 300? or 1200? Mic Input Impedance

Custom VU meter (input/output) with calibrated ballistics

Relay based selection of Line / Mic & DI Inputs

Overload input and output indicators

Reverse Phase Switch

Universal, on-board power supply

DESCRIPTION

Its fundamental design architecture retraces the path of revered, classic pre-amps of the past as well as our popular 7602. Our engineers at Chameleon have worked tirelessly in developing new, pivotal components that allow us to take the next step forward in performance.

These enhancements start with all-new proprietary microphone and line-level input transformers that feature custom-made nickel laminations and bobbin assemblies—all designed in-house. By developing new engineering processes focused on the material science associated with lamination manufacturing, Chameleon was able to develop a lamination “recipe” that delivers optimized audio performance, providing the 7603 with high bandwidth and incredibly low distortion.

Design of our new transformers was based around the need to capture and preserve the delicate audio input signals’ truest form, and so they are enclosed in high permeability MuMetal enclosures, designed to protect sensitive audio signals from radio frequencies, spurious and parasitic noises.

Once your audio exits the input transformer, our circuit boards are carefully crafted to ensure the highest possible signal integrity. As a starting point, we developed a new discrete audio input gain stage based on our vision for a solid topology that provides extremely low noise, high dynamics and extreme bandwidth. All of the 7603’s operational amplifiers used throughout the device are based on this topology.

The 7603 features EQ stages with four different available adjustments—Variable High Pass, Low Frequency Shelving, Mid Frequency and High Frequency Shelving. Our engineers made a conscious decision to stay with the same, desirable, inductor-based topology that made our 7602 so popular, however we implemented our new discrete Op Amp to drive signal through a new set of custom Chameleon designed and manufactured inductors, providing the musicality we all love to use.

The output stage of the 7603 is unique with respect to its design and performance. It can be described as a variable-gain circuit that simultaneously adjusts both the input and output levels in order to generate a lower noise floor and extraordinary audio performance.

The 7603 pre-amplifier provides a desirable set of user selectable functions designed to make the unit flexible and an integral part of the artistic process, incorporating a full portfolio of traditional features as well as some not commonly seen on other pre-amps.

Microphone input impedance can be selected between 300 and 1200 ohms, providing a method by which a microphone can be more ideally matched to the input stage and making it easier to get the best from lower output microphones such as ribbon-based designs.

We added a low impedance Direct Input on the front panel for plugging in instruments such as guitars that can be run through the line input stage, and added a precision VU meter with custom ballistics for visual monitoring of either the input or output levels.
