Wes Audio ngTubeEQ

Wes Audio ngTubeEQ

På lager og i Demo hos oss!

Ta kontakt for tilbud!

Next generation tube EQ with digital recall and automation

ANALOG SOUND, DIGITAL CONTROL
True ANALOG sound with extremely convenient control!
For decades, tube equalizers have been cherished for their rich, musical sound, shaping the sonic character of countless classic recordings. Our ngTubeEQ elevates this legacy, offering a refined, analog experience seamlessly integrated into the modern digital workflow. With its lush tonal quality and intuitive digital control, the ngTubeEQ is set to become an indispensable tool in studios worldwide, continuing our tradition of blending vintage charm with contemporary functionality. Experience the best of both worlds – the soul of vintage sound and the ease of digital technology with ngTubeEQ.



100% analog Tube Equalizer

ngTubeEQ is a 100% analog processing unit with 26dBu of headroom
Regardless of its full digital control, the analog signal path provides full amazing analog processing.
Heart of the unit = Passive section

Fully passive EQ section we all love.
Based on custom inductors.
4 Passive bands

12 frequency points per band.
Each band can be easily disabled.
Variable Q configuration.
Total frequency range from 22Hz to 28kHz.
Each band supports Bell or Shelf configuration.
LPF & HPF Active filters

Active circuit.
12dB/Oct or 24dB/Oct slope.
Whole circuit is fully bypassable on analog level.
Variable control.
3 Modes of operation

DUAL
STEAREO
MID-SIDE
Carnhill transformers

Transformers in audio compressors aren’t just for electrical isolation – they can add a warm, sonic saturation we all love in our recordings. Carnhill transformers are part of the ngTubeEq adding all that vintage flavor!



Total recall and control plugin

Unit implements full control and instant recall via DAW plug-in.
Support of all common plug-in formats and Digital Audio Workstations.
Completely new GUI engine and Intuitive UX design.
All parameters are accessible from the sweetspot.

Selectable output stage

GREEN – Electronically balanced for cleaner and punchy sound with less sonic imprint.
RED – Tube amplification stage, transformer balanced output stage with IRON PAD – this architecture allows to raise the output of the unit and hit the Tube Amplification stage and transformer section harder, while maintaining the same output signal through passive attenuation section.
Hardware A/B/C buttons to compare two independent settings

Even using ngTubeEQ as a pure analog signal processor you can easily switch between three parallel settings with the magic of a simple button.



THD – total harmonic distortion

Proprietary Harmonic distortion circuit.
Entirely bypassable through analog relay.
Variable control with 100 steps.
Integrated with internal gain structure to add inductor- based saturation.
Propotional and Constant Q

Proportional Q became part of many other EQ designs often described as being very musical – technically the more You boost the more narrow Q becomes.
Constant Q is on the other hand much more precise and very often desired by professional users to gain more control over the source material – this option doesn’t alter the Q of a particular band while gain is modified.
5dB/15dB Gain Mode

ngTubeEQ gains for each band can work either in 5dB or 15dB mode:
5dB ~0.1dB step
15dB ~ 0.25 dB step
Plugin Integrated metering

Precise Plugin metering from 0dBu to 26dBu with clip detection.

Interactive LCD Display: Real-Time Parameter Editing
Integrated high precision metering
Plug-in presets database

Plug-in of course features an unlimited number of presets.
Those presets can be categorized for user presets.
And we will also deliver units with some factory presets.
APP FOR MAC AND PC
Digital control features for fully analog units.
