2 i 6 digital 96kHz 64-bit audio kontroll med programvare, nettverkstilkobling,

GRATIS FRAKT

2 in 6 ut digital 96kHz 64-bits ljudstyrning med mjukvara, nätverkskoppling, kablar, flera valbara delningsfilter, 6-bands parametriska EQ:s, ställbara limiters, faskorrigering, tidsfördröjning, balanserade XLR in/ut, USB och nätverkskopplingar. Drömmen för varje installatör och ljudtekniker. Öppna pdf:en längst ned på länken.

Engelsk superkvalitet, Citronic DSM2-6 MKIII DIGITAL SPEAKER MANAGEMENT SYSTEM

A digital speaker management system which incorporates crossovers, EQ and limiters for speaker configurations of up to 2 inputs and 6 outputs. The unit enables the sound system designer to accurately control the inputs for each power amplifier, providing an ideal matched output suited to each speaker enclosure and its surroundings. A 96kHz 64-bit DSP processor has been utilised to ensure professional quality resolution, controlled either directly via the front panel or USB using the included software. This system provides high quality speaker management that is easy enough to use for basic PA applications, yet has enough features to satisfy the most demanding professional live sound technician.

2 input, 6 output fully balanced
Inputs: 6-band shelving or parametric EQ
Inputs: Phase and Gain correction
Outputs: Crossover types: L-R / Bessel / Butterworth
Outputs: 6-band parametric EQ
Outputs: Time correction delay

Outputs: Adjustable Limiter
All inputs/outputs independently controlled
Linkable via RS485 for expanded systems
RS-232 to RS-485 converter included
1U rack mountable
Software included for Win XP (PIII 500, 128MB RAM) or higher

Power supply AC 115V/230V 50Hz/60Hz
Fuse T315mA
Crossover L-R; Bessel; Butterworth.
PC Com Port USB and RS485 (RJ45)
CMRR 70dB @ 1kHz
Channel crosstalk 80dB @ 1kHz
Input/Output polarity In phase (+) or reverse (-)
Input EQ 6-band parametric EQ
Mute Any input or output channel
Limiter 6 x output (adjustable)
Output EQ 6-band: Hi/Lo-shelf or Para
Processor 96kHz, 32-bit DSP
Delay 0-1000ms
Display 2 x 24 character LCD + mute, edit & level LEDs
Frequency response 20Hz - 20kHz
Input impedance : Balanced 20kOhms
Input level +25dBu
Output gain –12dB
Output impedance : Balanced 100 ohms
Power consumption 25W
S/N ratio 110dB
THD 0.01% @ 0dBu/1kHz
Dimensions 483 x 44 x 220mm
Weight 3.19kg



CITRONIC, Engelsk superkvalitet sedan 40 år. Ett års garanti.

Delbetala från 180:-/månad eller ett år räntefritt

GRATIS FRAKT

BESTÄLL HÄR och se video, pdf, fler bilder:
http://www.billebro.se/myshop_start.php?PRID=5272

Billebro
1000 kvm butik Frejgatan 27
32 år i branschen - 30 dagar pengarna tillbaka garanti postorder
