CB PNI Escort radio station HP 9001 PRO ASQ adjustable, AM-FM, 12V / 24V, 4W, Sc

Mere info:

CB radio station, 12V / 24V power supply, AM / FM, multiband, 4W power.



Product identification
Product code PNI-HP9001P
Manufacturer PNI
General characteristics
Model Furniture
Broadband type AM / FM
channels 40
Frequency 26,965 - 27,405 MHz
Microphone type (pins) 6 pines
Power speaker audio 3 W
Sensitivity (20dB SINAD) less than 0.5 µV AM / FM
Emission power 4 W
Modulation FM: 1.8KHz 0.2KHz, AM: 85-95%
feeding 12 V / 24 V
Current absorbed maximum 2200mA
Dimensions (W x H x H / Weight) 46 x 142 x 158 mm / 500g
1DIN mounting Yes
Special features
Dual Watch Yes
Scan channels Yes
ASQ Yes
Lock the keyboard Yes
LCR - the last channel selected Yes
Adjustable ASQ Yes
Noise filter ANL (Automatic Noise Limiter)
Multicolored screen Red, Green, Purple, Blue, Yellow
Channel memory Yes
Operating temperature -26 C ~ + 60 C
Rear panel connections
Additional speaker connection Yes
Microphone connection Yes
The package contains
Radio station Yes
Microphone Yes
Support and screws holding radio station Yes
Microphone mounting bracket and screws Yes
Power cable Yes
Lighter plug Yes
User manual Yes
