Schneider Electric Compact LV432700

Product Details

The Schneider Electric Compact NSX400N is a complete 4P 4d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic Micrologic 5.3 A trip unit, with 400A rating. Micrologic 5.3 A trip unit provides adjustable long time, short time and instantaneous protection. Micrologic 5.3 A has an embedded display unit for fine settings adjustment and display of the currents (ammeter).

Display type LCD display

Type of measurement Ammeter

Specifications

Attribute Value

Range ComPact

Series LV43

Number of Poles 4

Current Rating 400A

Mounting Style Fixed

se mer på

https://no.rs-online.com/web/p/mccbs/2211030/

https://docs.rs-online.com/0a65/A700000007872326.pdf

https://www.se.com/ww/en/product/LV432700/circuit-breaker-compact-nsx400n%2C-50-ka-at-415-vac%2C-micrologic-5.3-a-trip-unit-400-a%2C-4-poles-4d/
